Amana Tool 45468 1-1/8" Dia. Flush Trim/Pattern Plunge Router Bit

SHIPPING OPTION(S): GROUND, LTL TRUCK, AIR

PRODUCT CODE: AM-45468

This bit is essentially a plunge-cutting straight with a shank-mounted ball-bearing pilot. It is a versatile bit, useful for template/pattern routing of parts, joints, and internal cuts, and can be used in handheld and table-mounted routers. The template is attached to the workpiece, and the pilot bearing rides along its edge as the cutting edges rout the workpiece, forming an exact duplicate of the template. With a handheld router, the pattern is on top of the work; with a table-mounted router, the pattern is underneath the work.

$55.00

PRODUCT CODE

AM-45468

Details

Flush Trim Templating / Pattern PlungeRouter Bit For Solid Surface Material
This bit is essentially a plunge-cutting straight with a shank-mounted ball-bearing pilot. It is a versatile bit, useful for template/pattern routing of parts, joints, and internal cuts, and can be used in handheld and table-mounted routers. The template is attached to the workpiece, and the pilot bearing rides along its edge as the cutting edges rout the workpiece, forming an exact duplicate of the template. With a handheld router, the pattern is on top of the work; with a table-mounted router, the pattern is underneath the work.

	D	B	d	L	Replacement Bearing	Replacement Collar	Tool No.
	1-1/8	1-1/2	1/2	3-1/2	47738	47740	AM-45468

Maximum RPM Guide For Amana Tool Router Bits
Do not exceed the maximum RPM shown for the particular tool you are using. Max RPM for symmetrical tool only!

Router Bit Dimensions	Max RPM
2" (Less than 50)	28,000
2" - 2-3/8" (50-60mm)	22,000
2-3/8" - 2-3/4" (60-70mm)	19,000
2-3/4" - 3-1/4" (70-80mm)	16,000
3-1/4" - 3-5/8" (80-90mm)	15,000
3-5/8" < (90-100mm)	13,000

Note: Please also refer to laser etching on router bit shank for most updated RPM speed rating.
